MONITORING > FM8 CTG

he FM series of Fetal Montitoring are the next generation of medical devices. The FM8 model is the latest in a series of accuity fetal monitoring products. With a large crisp 8 inch color display with tilt function, you would be hard pressed to miss a beat.

Function
1.Compact design, it can be placed horizontally or hung on the wall.
2.Color LCD, 60° convertible screen
3.Display monitoring curve and data clearly
4.Area mark for normal FHR(120 BPM~160 BPM).
5.Manual record for fetal movement.
6.Alarm for abnormal FHR
7.Real-time monitoring for continuous 24 hours.
8.Storage, playback and print the monitoring curve for continuous 12 hours.
9.Optional interface languages: Chinese and English.
10.Optional twins monitoring.
11.9-crystal and broad beam transducer.
12.Extra long-life and high-resolution built-in thermal printer.
13.Communicate with central monitoring system by the built-in RJ45.

Specification
Safety
Type of protection against electric shock: Class Ⅰ
Degree of protection against electric shock: Type B applied part
Working Voltage: AC 100 V~240 V
Frequency: 50 Hz/60 Hz
P＜60 VA
Fuse: T1.6AL250V
Print
Record paper: Z-fold paper
Print width: 112 mm
Valid print width: 104 mm
Paper speed: 1 cm/min, 2 cm/min, 3 cm/min(optional)
Network interface: RJ 45
Ultrasound probe
Nominal Frequency: 1.0 MHz
Work Frequency: 1.0 MHz±10%
Negative peak sound pressure : p_<1 MPa
Output beam intensity : Iob<20 mW/cm2
The peak time space peak intensity: Ispta<100 mW/cm2
The average time space peak intensity: Isata<10 mW/cm2
FHR
Range: 50 BPM~240 BPM
Resolution: 1 BPM
Accuracy: ±2 BPM
TOCO
Range: 0~100%
Resolution: 1%
Nonlinear error: ≤±10%
RZ way: manual
Fetal Marking
Manual button

Accessories
A three-in-one Transducers(Ultrasound TransducerⅠ, TOCO Transducer, Remote Marker)
A User Manual
Two abdomen belts
An earth line
Record paper(two sets)
A power cord
Two Fuses
